For Technical assistance, please contact:
Steve Kolling
HCPA Tech Advisor techadvisor@hcpapresents.com |
 |
Lighting
- ETC Express 72/144 v3.1 console
- ETC Remote Focus Unit
- ETC Sensor+ dimming system (216 circuits)
- Unison Lighting Control System
- DMX addressing
- 4 electrics (flying) plus FOH catwalk
(12) 19-degree ETC Source Four 750 ellipsoidals
(24) 26-degree ETC Source Four 750 ellipsoidals
(11) 36-degree ETC Source Four 750 ellipsoidals
(23) Altman 6" fresnels (Cat # 165Q)
(10) ETC Source Four 750 6" PAR
(6) Lighting & Electronics, Inc PAR 64 (work lights)
(12) Lighting & Electronics, Inc broad cycs (Cat # 6571) (on 4th electric)
- FOH to front of stage = 22 feet, height of FOH from stage = 29 feet
- 2 Lycian Midget HP Model 1209 follow spots
Sound
Control Booth Rack
- Soundcraft GB8 40-channel (8 grp/aux) mixer
- Alesis CD recorder
- Denon CD player + cassette
- Shure SLX4 wireless mics (8)
- Rane mic inputs (4)
- Rane line inputs (4)
- 28-XLR sends from clusters around the stage to booth
Backstage Rack
- Shure Soundplex DSP P4800 system processor
- dbx 231 2-channel 31-band graphic equalizer
- Symetrix 302 Dual Microphone Preamplifier
- Atlas Sound SACR-191 Sequential Switch System
- Peavey Architectural Acoustics IPA 150T II power amplifier
- Peavey Architectural Acoustics UMA 1502 integrated modular amplifier
- Crown CTs 600 power amplifiers (3)
- Monitor outs (8) / Aux1 (2) / Aux2 (2)
- Community FOH speakers and 7 stage monitors
- Telex mic/headsets
- Telex Soundmate personal listening system
- Audiocom WM2000 communication system
Stage
(Dimensions)
- Load-in is through 10'x20' roll-up doors
- JLG 2630ES scissors lift Pro-Fit Series
1835 lb capacity
800 lb maximum at 20'
500 lb maximum at 25'
- Mister KOOL stage fogger
- 750 seat house
- Dressing rooms are adjacent to the stage.
- Power leads are ordinary Edison outlets and extension cords
- Wired communications system (including dressing rooms)
- 8-year-old Kawai 7’ grand piano with adjustable bench.
- Standard chorus risers (18" depth). Conductor’s podium
- Six 6- by 8-foot platforms – adjustable at either 18- or 24-inches with blue skirting
- Chairs and music stands are a standard high school band variety
- Light Blue cyc
|
